Beschreibung
Laser Type Diode-pumped solid-state laser Nd:YVO4
Laser Power 0-3W
RECOATING SYSTEM Intelligent reduced vacuum press recoater
Beam (diameter Φ) 0.10-0.5mm laser spot are adjustable
Focus style High Speed Scanning Galvanometer
Part drawing speed Recommended 6.0m/s,Max scan speed :18m/s
Beam jump speed Recommended 10.0m/s ,
RESIN VAT Volume Approx. 222.0L (230kg) Z-axis:400mm
Build envelope: 600mm(X)*600mm(Y)*400mm(Z)
SOFTWARE
Operating system Patent ZERO 7.0 ,Windows 10, Ethernet, IEEE802.3
Build software ZERO Patent build software :3D Layer
INSTALLATION CONDITION
Power 200-240VAC 50/60Hz, single phase, 5/10Amps
Ambient temperature 20-26ºC
Relative humidity Less than 40%, non-condesing
Machine Size 1450mm(W)*1050mm(D)*1850mm(H)
Machine Weight Approx. 830Kg
WARRANTY Optional :1-5 years
Laser 6000 hours or 23 months (whichever comes first)
Main machine
two (2) years from the date of delivered machine
